Polyline Direction
by A>V>C>AutodeskFree
Change curve direction and start points in AutoCAD for CNC contour preparation and other tasks involving curve paths.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
Polyline Direction displays the orientation and start point of curves in AutoCAD with temporary colors, markers, and arrows. It can reverse one curve or assign clockwise or counterclockwise orientation to selected closed curves. Start points can be changed individually or assigned across selected curves using specified positions. The program also filters participating objects by type, layer, or length and provides configurable operating modes.
Key capabilities
from the Autodesk App Store listingCurve orientation display
Shows the direction of curves with temporary colors, arrows, and markers at their start points.
Group direction editing
Changes orientation for individual curves or selected groups and assigns a clockwise or counterclockwise direction to closed curves.
Start point editing
Changes the beginning point of one curve or assigns start points to selected curves.
Curve object coverage
Processes lines, polylines, splines, and arcs, while circles and ellipses are converted for direction and start-point assignment.
Object filtering
Limits participating drawing objects by object type, layer, or minimum length.
Configurable operation
Provides seven command modes and up to nine saved settings styles.
Use cases
- Preparing contour paths for milling or laser cutting with CNC equipment.
- Setting cutter entry points and traversal direction for closed contours.
- Checking curve orientation and start points across visible or selected drawing objects.
In the catalog
201 plugins in AutoCAD · Productivity & Utilities
Price distribution: 72 free, 1 freemium, 128 paid
Pricing & deployment
Platform
Autodesk
Product
AutoCAD
Deployment
Desktop
Pricing
Free
More from A>V>C>
Similar plugins in AutoCAD · Productivity & Utilities
View all 201 →
Autodesk Data Exchange Connector for Revit®
Share selected Revit model elements and properties with Autodesk and non-Autodesk applications.
Autodesk, Inc.Free
Detail F/X
Manage, draft, call out, and update office CAD details within AutoCAD.
Land F/XPaid
Parametric Pipe Supports Plugin
Models parametric piping supports in AutoCAD Plant 3D with adjustable sizing and customization.
Mirza SolutionsPaid
What the vendor says
«To prepare contours for milling or laser cutting on a CNC, it is important to set the correct direction of the cutting lines, the correct clockwise or counterclockwise bypass of closed contours. In addition, it is important at what point of the contour the cut will begin, the entry point of the cutter. To solve these …»
