MultiSlice
by A>V>C>AutodeskPaid
Slices AutoCAD 3D solids into sheet-material parts, with optional miter joints and material or layer assignment.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
MultiSlice cuts AutoCAD 3D solids into slices for boxes, columns, and partitions made from sheet materials. It can process selected surfaces across multiple solids, create miter joints, and preserve the remaining core. Cut parts can be joined into one solid, assigned layers or materials, and given the source surface color or material. The plugin works with 3D solids only, not meshes, surfaces, or blocks.
Key capabilities
from the Autodesk App Store listingBatch solid processing
Processes multiple 3D solids in one operation.
Surface selection
Selects individual, contiguous, or all surfaces for cutting.
Miter joint creation
Creates miter joints between parts along the bisector of the joint angle.
Slice style settings
Stores up to nine slice styles that can be switched from the command line.
Surface cutting methods
Provides three peeling methods for flat, cylindrical, and more complex surfaces.
Core preservation
Can save the remaining core of the original solid.
Part attribute transfer
Can transfer selected surface color and material or assign a layer and material to all parts.
Slice merging
Can join all cut slices into one solid.
Use cases
- Modeling columns and walls from particleboard or plywood.
- Preparing internal-part designs while retaining the original solid core.
In the catalog
201 plugins in AutoCAD · Design & Engineering
Price distribution: 72 free, 1 freemium, 128 paid
Pricing & deployment
Platform
Autodesk
Product
AutoCAD
Deployment
Desktop
Pricing
Paid
More from A>V>C>
Similar plugins in AutoCAD · Design & Engineering
View all 201 →
Autodesk Data Exchange Connector for Revit®
Share selected Revit model elements and properties with Autodesk and non-Autodesk applications.
Autodesk, Inc.Free
Detail F/X
Manage, draft, call out, and update office CAD details within AutoCAD.
Land F/XPaid
Parametric Pipe Supports Plugin
Models parametric piping supports in AutoCAD Plant 3D with adjustable sizing and customization.
Mirza SolutionsPaid
What the vendor says
«The MultiSlice command will help you quickly create boxes, columns, and partitions from sheet materials. Simply draw the cubes with the _box command in the size of future products and call the MultiSlice (MSL) command. The command will do the rest: • Processes a lot of solids at once. • Selects only the surfaces you …»
