Fixture
by A>V>C>AutodeskPaid
Place furniture fixtures and fasteners along right-angle solid joints in AutoCAD.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Fixture identifies suitable joints between flat solid parts and places selected fixture blocks along them. It supports fittings, fasteners, hinges, shelf holders, brackets, locks, dowels, biscuits, and other hardware. Placement settings include edge distances, spacing methods, alignment, mounting depth, symmetry, and joint-length limits. Fixture blocks can come from a template or another drawing, and custom blocks can be created. The add-in can also place fixtures across gaps and rotate them to match the parts.
Key capabilities
from the Autodesk App Store listingJoint detection
Finds adjacent flat surfaces between selected solid parts and identifies suitable joints for fixture placement.
Fixture placement
Arranges fixture blocks along the long side of a joint and rotates them to match the parts.
Fixture library
Includes blocks for RTA fittings, fasteners, hinges, shelf holders, brackets, catches, dowels, biscuits, locks, latches, and other hardware.
Custom fixtures
Allows fixture blocks with correctly prepared internal solids to be created and used.
Spacing controls
Supports fixed edge margins, fixed spacing steps, adjustable first-fixture distances, and maximum repeated-fixture steps.
Alignment settings
Adjusts mounting depth, center alignment, corner distance, and furniture-standard 32 mm positioning.
Drawing block sources
Selects fixture blocks from template files or other drawings and copies them into the current drawing.
Fixture size checks
Checks whether selected parts are large enough for the dimensions of the chosen fixture.
Use cases
- Furniture and product designers can arrange hardware on right-angle connections between particleboard or MDF parts.
- Fabrication workflows can limit fixture placement to the width of a drilling machine and distribute fasteners from both joint ends.
- Custom command buttons and palettes can be created for arranging different fixtures.
