Flat

by A>V>C>AutodeskPaid
Download & Try Add to compare

Generate flat drawings from AutoCAD objects by projecting them onto the XY plane.

Facts verified marketplace.autodesk.comAd-free rankings
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
Flat — cover image

What it does

Flat projects AutoCAD drawing objects onto the XY plane, including solids, meshes, surfaces, regions, bodies, faces, and curves. It can process objects inside blocks, arrays, and external references, and can convert certain 2D and 3D polylines to regular polylines. Projections can use the current UCS, with results assigned to MD_Visible and MD_Hidden layers unless that option is disabled. The command also supports configurable offset styles and can optionally delete the source object.

Key capabilities

from the Autodesk App Store listing

Object projection

Projects supported AutoCAD objects onto the XY plane or the current UCS.

Mesh conversion

Converts meshes, polygon meshes, polyface meshes, surfaces, regions, bodies, and faces into lines.

Curve flattening

Projects three-dimensional and non-XY planar curves onto the target plane.

Nested object processing

Flattens suitable objects inside blocks, arrays, and external references.

Annotation transfer

Moves text annotations from different planes to the XY plane without changing their shape.

Layer assignment

Places results on MD_Visible and MD_Hidden layers, with an option to disable this redistribution.

Offset style presets

Stores up to nine offset styles that can be switched from the command line or a macro.

Use cases

  • Create room layouts from drawings exported from 3ds Max that contain meshes and unusual 2D polylines.
  • Prepare flattened, Z-twisted splines and polylines as contours for Extrude.

In the catalog

201 plugins in AutoCAD · Documentation & Drafting

Price distribution: 72 free, 1 freemium, 128 paid

More Autodesk plugins • Documentation & Drafting plugins

Pricing & deployment

Platform
Autodesk
Product
AutoCAD
Deployment
Desktop
Pricing
Paid

More from A>V>C>

Similar plugins in AutoCAD · Documentation & Drafting

View all 201 →

What the vendor says

«section planes, FlatShot and SolProf commands. But they are all very limited and have so many drawbacks. The A>V>C> Flat (FLT) command can roll out any drawings to the plane, all drawing objects. FLT has the following advantages and features: • • Works without preliminary preparation, does not ask for anything …»
