AVC Slice
by A>V>C>AutodeskPaid
Peels flat or curved surfaces from solids in AutoCAD to model sheet-material parts.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
AVC Slice removes a specified thickness from selected flat or curved solid surfaces without requiring a cutting plane or supporting construction. It can process multiple contiguous surfaces, join slices from connected surfaces into one solid, or save separated fragments as individual solids. Surface color and material can be transferred to cut solids, with optional layer and material assignment. The command supports repeated operations, command-line settings, macros, and up to nine slice styles.
Key capabilities
from the Autodesk App Store listingCurved surface peeling
Peels material from cylindrical, conical, and other curved solid surfaces.
Multiple surface selection
Processes several surfaces on one solid at the same time.
Adjacent surface detection
Finds and adds contiguous surfaces that meet without kinks.
Fragment handling
Joins slices from contiguous surfaces into one solid or saves separated fragments as individual solids.
Material transfer
Transfers selected surface color and material to cut solids, with options to assign a layer and material.
Slice style settings
Provides up to nine configurable slice styles that can be switched from the command line.
Use cases
- Modeling furniture and other products made from sheet materials.
- Creating thin curved plating without preliminary construction or coordinate-system changes.
In the catalog
201 plugins in AutoCAD · Productivity & Utilities
Price distribution: 72 free, 1 freemium, 128 paid
Pricing & deployment
Platform
Autodesk
Product
AutoCAD
Deployment
Desktop
Pricing
Paid
