UCS Derived Component
by FreeradicalAutodeskFree
Places and updates derived components in Inventor using two UCS references.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Inserts and moves derived parts. The derived feature is positioned using two UCS references: one in the derived part and one in the document where the feature is placed. Its position updates when that document's view becomes active or the document changes.
Key capabilities
from the Autodesk App Store listingDerived Part Insertion
Inserts a derived part.
Derived Part Movement
Moves an inserted derived part.
UCS Positioning
Positions the derived feature using two UCS references.
Position Updating
Updates the position when the feature's document view becomes active or the document changes.
In the catalog
513 plugins in Inventor · Design & Engineering
Price distribution: 158 free, 4 freemium, 351 paid
Pricing & deployment
Platform
Autodesk
Product
Inventor
Deployment
Desktop
Pricing
Free
More from Freeradical
Similar plugins in Inventor · Design & Engineering
View all 513 →
iCable
Create and report cables, wires, hoses, tubes, and pipes in Autodesk Inventor assemblies.
Limin MaPaid
Model Query
Query and visualize Inventor assembly components by standard, custom, or physical properties.
Bas Automation ServicesPaid
Woodwork for Inventor®
Design 3D furniture, prepare manufacturing data and drawings, support CNC preparation, and arrange sheet parts in Autodesk Inventor.
Čeli APSPaid
What the vendor says
«派生パーツを挿入し、移動します。 派生フィーチャーは、派生パーツと派生フィーチャーが配置されるパーツにある2つのUCSで位置決めされます。 位置は、以下の条件で更新されます。 (1) UCS派生フィーチャーがあるドキュメントのビューがアクティブになった時。 (2) UCS派生フィーチャーがあるドキュメントが変更された時。 ですので、派生パーツのドキュメントを更新してもUCS派生フィーチャーを含むドキュメントに影響が及ばない場合は、位置が更新されないので注意してください。 位置更新はこのアドインにて実行されています。 このアドインをアンロードすると、位置は更新されずにUCS派生パーツフィーチャーは最後の場所に留まります。»
