FX64 Plot 2027
by FX64 Software SolutionsAutodeskPaid
Prints and converts Inventor drawing files, including files associated with assemblies and files stored in Vault.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
What it does
FX64 Plot selects drawings associated with an Inventor project and assembly, then prints or converts the selected files. Printing uses configured devices and paper formats, while conversion supports PDF, TIFF, JPEG, DXF, DWG, DWF and neutral CAD formats. Results can be copied, moved, saved to target folders or checked into Vault. The program can also apply timestamps and watermarks, define filenames from iProperty values, and trigger processing when a drawing is saved.
Key capabilities
from the Autodesk App Store listingAssembly drawing search
Searches for drawing files associated with an assembly and its components.
Batch printing
Selects printer devices and paper formats automatically from configured drawing-format settings.
Multi-format conversion
Converts selected drawings to PDF, TIFF, JPEG, DXF, DWG, DWF, STEP, IGES, SAT, STL and other neutral CAD formats.
Vault file processing
Processes files stored in Vault and can upload and check in converted formats.
Output file routing
Copies results to a target location, saves them in separate folders or places them beside the source drawings.
Drawing stamps
Adds timestamps and watermarks to printed or converted sheets.
iProperty filenames
Creates converted filenames from model or drawing iProperty values and timestamps.
Automatic processing
Can start printing or conversion when a drawing is saved.
How it compares
CAD4PLT prints drawings from one or more Inventor assemblies directly from Vault and exports them as PDFs, while FX64 Plot also converts drawings to multiple listed formats and supports file-system searches and imported file lists. cSys Pdf AutoSave Premium 2027 and 2026 create PDF copies during the Inventor Save command, whereas FX64 Plot supports batch selection, printing and conversion to multiple formats.
| Name | Pricing | Deployment | Updated |
|---|---|---|---|
| this plugin | Paid | Desktop | |
| CAD4PLT | Paid | Desktop | |
| cSys Pdf AutoSave Premium 2027 | Paid | Desktop |
In the catalog
31 plugins in Inventor · Documentation & Drafting
Price distribution: 4 free, 27 paid
Pricing & deployment
Platform
Autodesk
Product
Inventor
Deployment
Desktop
Pricing
Paid
More from FX64 Software Solutions
Similar plugins in Inventor · Documentation & Drafting
View all 31 →
cSys Pdf AutoSave Premium 2027
Automatically saves modified Inventor drawings as PDF copies during the Save command.
CodeSystems Finland Inc.Paid
cSys Pdf AutoSave Premium 2026
Automatically saves modified Inventor drawings as PDF files during the Save command.
CodeSystems Finland Inc.Paid
iCable Professional
Model routed electrical and fluid conduits within Autodesk Inventor assemblies.
Limin MaPaid
What the vendor says
«Go to https://www.fx64online.com/de/downloads and request your serial number for a 14-day test with full functionality. NOTE: As of version 2027, the Autodesk® Inventor® Apprentice Server is no longer included in the standard Inventor installation and must be installed manually. FX64 Plot requires the Inventor …»
