QUICK PLAN VIEW
by Andrzej KalinowskiAutodeskPaid
Aligns the AutoCAD view with selected geometry or screen points and adjusts the working coordinate system.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
Rotates the AutoCAD view based on a selected object, two screen points, or a segment from a line or polyline. It also zooms toward the chosen location and changes the working coordinate orientation to match the view. The add-in supports several linear object types, including lines, polylines, multilines, walls, and other linear AutoCAD or AutoCAD MEP objects.
Key capabilities
from the Autodesk App Store listingGeometry-based alignment
Reorients the view using a selected object, pair of screen points, or line or polyline segment.
Selection zoom
Automatically zooms toward the selected location.
View-based coordinates
Changes the User Coordinate System so it follows the current view.
Linear object support
Supports lines, LW-polylines, multilines, 3D polylines, 2D polylines, walls, and other linear AutoCAD or AutoCAD MEP objects.
Use cases
- Viewing portions of building projects with complex angular forms.
- Working on underground heating or sanitary networks whose routes change direction.
