CONNECT MEP OBJECTS
by Andrzej KalinowskiAutodeskPaid
Connects AutoCAD MEP ducts, pipes and cable trays, or starts new runs from object ends.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
Provides AutoLISP routines for connecting AutoCAD MEP objects after selecting their ends. It can also draw a new run from the end of an existing object. The routines use AutoCAD MEP connection rules and may fail when AutoCAD MEP cannot calculate or complete a connection. Routing Preferences must be configured for piping, HVAC and electrical objects.
Key capabilities
from the Autodesk App Store listingConnect MEP objects
Connects AutoCAD MEP objects such as ducts, pipes and cable trays after their ends are selected.
Draw new runs
Starts a new MEP run from the end of an existing object.
AutoLISP routines
Provides a set of AutoLISP routines for connecting or extending AutoCAD MEP objects.
Use cases
- Extending piping, HVAC or electrical object runs from an existing endpoint.
- Connecting two MEP objects when the standard endpoint selection workflow is being used.
