Python Lined Pipe
by Tamas HalaszAutodeskPaid
Create lined or standard-wall pipe parts, bends, tees, and wyes in Plant 3D.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Python Lined Pipe provides scripts and catalogues for creating pipe segments, bends, tees, and wyes in Plant 3D. Parts can use lined or normal wall thickness and loose flanges on all sides. The Python scripts can be used to create custom parts based on applied standards, and some standard sizes are included.
Key capabilities
from the Autodesk App Store listingPipe segment creation
Creates pipe segments, also referred to as sleeves, with lined or normal wall thickness.
Fitting creation
Creates bends, tees, and wyes.
Loose flange support
Adds loose flanges on all sides of the pipe parts.
Custom part scripting
Provides Python scripts for creating parts based on applied standards.
Standard size catalogues
Includes some standard sizes.
In the catalog
513 plugins in Plant 3D · Design & Engineering
Price distribution: 158 free, 4 freemium, 351 paid
Pricing & deployment
Platform
Autodesk
Product
Plant 3D
Deployment
Desktop
Pricing
Paid
