ASME Python Flanges and Gaskets
by Piping ContentAutodeskPaid
Adds parametric Python piping components, including flanges, gaskets, bolts, and pipe parts, for Plant 3D.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
What it does
Provides Python-based piping parts including flanges, gaskets, bolts, and pipe components. The catalog covers several flange and gasket forms, pressure classes from #150 to #2500, and listed sizes from 1/2" to 24". Component parameters and preview images are available in Properties, and the vendor states that isometric drawings can be generated for the parts. The vendor also states that the piping outside diameter is compatible with ASME standards and that the components meet ASME B16.5 standards.
Key capabilities
from the Autodesk App Store listingPython piping parts
Includes Python-based flanges, gaskets, bolts, and pipe components.
Flange selection
Offers blind, weld-neck, socket-weld, and threaded flange variants with RF or RTJ facing.
Gasket selection
Includes flat, full-face, octagonal RTJ, and spiral-wound gasket types.
Pressure classes
Lists components for pressure classes #150, #300, #600, #900, #1500, and #2500.
Component sizes
Lists component sizes from 1/2" to 24", with ranges varying by component.
Parametric parts
Allows the listed flange and gasket parts to be adapted through their parameters.
Property previews
Displays component parameters and preview pictures in Properties.
Isometric drawings
Provides isometric drawing settings for the listed parts.
