Python for Tri-clamp and coupling
by Piping ContentAutodeskPaid
Provides custom Python-script components for clamps, couplings, ferrules, and gaskets.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Provides custom Python-script components for two-segment, three-segment, and high-pressure clamps, couplings, ferrules, and gaskets. Ferrules and gaskets connect with the clamps, and isometric symbols are included. The catalog contains entries for DIN-11850 Series 2, EN-10357 Series A, and DIN 11866 Series A. Pipe ID and OD values can be changed in the catalog.
Key capabilities
from the Autodesk App Store listingClamp components
Includes two-segment, three-segment, and high-pressure clamps from DN10 to DN150.
Coupling components
Includes couplings from DN10 to DN100.
Ferrule and gasket parts
Includes ferrules and gaskets from DN10 to DN150 that connect with the clamps.
Isometric symbols
Provides isometric symbols for the listed components.
Standards catalog
Includes a pre-built catalog for DIN-11850 Series 2, EN-10357 Series A, and DIN 11866 Series A.
Editable pipe dimensions
Allows pipe ID and OD values to be changed in the catalog.
In the catalog
513 plugins in Design & Engineering
Price distribution: 158 free, 4 freemium, 351 paid
Pricing & deployment
Platform
Autodesk
Deployment
Desktop
Pricing
Paid
