Universal Nozzle Content Pack
by Piping ContentAutodeskPaid
Provides a catalog of standard and default piping nozzles, including tube, flange, clamp, union, threaded, and socket-weld types.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
Provides piping nozzles in tube, flange, clamp, union, threaded, socket-weld, studding outlet, sanitary tank connection, and end-connection categories. The catalog lists nozzle options associated with specified BS, EN, ASME, DIN, ISO, API, AS/NZS, and SMS standards, along with pressure classes, schedules, and connection codes.
Key capabilities
from the Autodesk App Store listingTube nozzle catalog
Includes tube nozzle options linked to the listed BS, A270, EN, ASME, and ISO specifications.
Flange nozzle catalog
Includes flange nozzles with listed EN, ASME, DIN, API, and AS/NZS specifications, including pressure classes from 150# through 2500#.
Clamp and union types
Includes clamp nozzles and male or female union nozzles with the listed sanitary and piping specifications.
Sanitary tank connections
Includes bevel-seat ferrules, IPS tank nozzles, and TRICLAMP tank ferrules with specified connection codes.
End connection options
Includes threaded, bevelled, plain, and grooved end nozzles with specified NPT, BSP, schedule, pressure-class, and Victaulic-compatible options.
Python scripts
The package contains default and custom Python scripts.
In the catalog
1,097 plugins in Productivity & Utilities
Price distribution: 389 free, 19 freemium, 689 paid
Pricing & deployment
Platform
Autodesk
Deployment
Desktop
Pricing
Paid
