Plot by Revision
by PIXELTOOLSAutodeskFree
Selects Revit sheets for printing by revision, schedule, parameter, or text filter.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
Plot by Revision selects Revit sheets for a print session using revisions, sheet schedules, custom parameters, or sheet number and name. Revision filters can include all revisions, revision clouds only, or manual revisions, while schedule data can be imported from any column. Sheet selections can be saved, reordered by drag and drop, and displayed with custom parameter columns. The add-in uses Revit's session print selection and does not create or modify saved view or sheet sets.
Key capabilities
from the Autodesk App Store listingRevision selection
Displays revisions with sheet counts and adds sheets associated with selected revisions to the print selection.
Schedule integration
Imports sheet numbers from any column in a Revit sheet schedule.
Parameter filtering
Filters sheets by discipline, phase, area, or another custom parameter and displays unique values with sheet counts.
Text filtering
Filters sheet numbers or names using wildcards and regular expressions.
Saved selections
Saves sheet selections for reuse and automatically saves the latest session.
Sheet reordering
Reorders selected sheets by drag and drop with multiple selection support.
Custom columns
Adds sheet parameters as columns, including revision, revision date, or custom fields.
Use cases
- Prepares print packages for projects with frequent revisions.
- Builds delivery packages from sheet schedules that already contain filtered sheet numbers.
- Prepares packages responding to supplements.
Who it's for
Project managers, BIM coordinators, document managers, and people preparing print packages.
