Plot by Revision

by PIXELTOOLSAutodeskFree
Download & Try Add to compare

Select Revit sheets for printing by revision, schedule data, or custom parameters.

Facts verified marketplace.autodesk.comAd-free rankings
PRICINGFree
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
Plot by Revision — cover image

What it does

Plot by Revision selects Revit sheets for printing using revisions, sheet schedules, custom parameters, or text filters. Revision selection can include cloud-only, manual-only, or all revisions, while schedule integration imports sheet numbers from any schedule column. Selections can be saved, reordered by drag and drop, and run within the current Revit session without creating or changing saved views or sheet sets. The vendor states that it supports nine languages and automatically detects the Revit language.

Key capabilities

from the Autodesk App Store listing

Revision-based selection

Displays revisions and sheet counts, then adds sheets associated with selected revisions to the print set.

Schedule integration

Imports sheet numbers directly from any column in a Revit sheet schedule.

Parameter filtering

Filters sheets by discipline, phase, area, or other custom parameters and displays unique values with sheet counts.

Text filtering

Filters by sheet number or name using wildcards and full regular expressions.

Saved selections

Saves sheet selections for reuse and automatically saves the previous session.

Sheet reordering

Reorders selected sheets by dragging, including multi-selection.

Custom columns

Adds sheet parameters such as revisions, revision dates, or custom fields as columns.

Use cases

  • Project teams can select sheets for frequently revised packages, ASI responses, and submissions.
  • Document administrators can import sheet numbers from a pre-filtered schedule when preparing a submission package.
  • Teams can select sheets by discipline, phase, area, or other project-specific parameter values.

Who it's for

The vendor names project managers, BIM coordinators, document administrators, and others who prepare print packages.
