Plot by Revision
by PIXELTOOLSAutodeskFree
Selects Revit sheets for printing by revision, schedule values, text, or custom parameters.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
Select sheets for an in-session Revit print set using revisions, sheet schedules, custom parameters, or sheet number and name filters. Revision filtering can include all revisions, revision clouds, or manually added revisions. Sheet numbers can be imported from any sheet schedule column, and selected sheets can be reordered by drag and drop. Selection sets can be saved for reuse, with the latest session saved automatically.
Key capabilities
from the Autodesk App Store listingRevision-based selection
Shows revisions with sheet counts and adds sheets associated with selected revisions to the print selection.
Schedule-based selection
Imports sheet numbers from any column in a Revit sheet schedule.
Parameter filtering
Filters sheets by title block, phase, zone, or another custom parameter and shows unique values with sheet counts.
Text filtering
Filters sheets by number or name using wildcards and regular expressions.
Saved selection sets
Saves sheet selections for reuse and automatically saves the latest session.
Sheet reordering
Reorders selected sheets by drag and drop with multiple selection support.
Custom columns
Adds sheet parameters as columns, including revision, revision date, and custom fields.
Use cases
- Prepare submission packages from sheet schedules that have already been filtered.
- Manage print sets for projects with frequent revisions, supplemental responses, or submission packages.
Who it's for
Project managers, BIM coordinators, document managers, and people preparing print packages.
In the catalog
555 plugins in Revit · Productivity & Utilities
Price distribution: 176 free, 1 freemium, 378 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Free
