Plot by Revision
by PIXELTOOLSAutodeskFree
Selects Revit sheets for printing by revision, sheet schedule, or custom parameter.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
Plot by Revision selects Revit sheets for printing using revisions, sheet schedules, or custom parameters. Revision filters can include clouded, manual, or all revisions, while parameter filters can use disciplines, phases, areas, or other custom fields. The app uses Revit's session print selection without creating or changing saved view or sheet sets. Selected sheets can be saved, reordered, filtered by text, and displayed with custom parameter columns.
Key capabilities
from the Autodesk App Store listingRevision selection
Shows revisions with sheet counts and adds sheets associated with selected revisions to the print selection.
Sheet schedule import
Takes sheet numbers from any selected column in a sheet schedule.
Parameter filtering
Filters sheets by discipline, phase, area, or another custom parameter and shows unique values with sheet counts.
Text filtering
Filters by sheet number or name using wildcards and full regular expressions.
Saved selection sets
Saves sheet selections for reuse and automatically saves the most recent session.
Sheet reordering
Reorders selected sheets with drag and drop and supports multiple selection.
Custom columns
Adds sheet parameters as columns, including revision, revision date, or custom fields.
Use cases
- Project managers can prepare submission packages from sheets already filtered in a sheet schedule.
- BIM coordinators can assemble print selections for frequent revisions and change requests.
Who it's for
Project managers, BIM coordinators, document managers, and others who prepare print packages.
