PAPER_SHEET_FORMAT
by Andrzej KalinowskiAutodeskPaid
Create scaled paper sheets and set plot scope in AutoCAD using standard or custom sizes.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
What it does
PAPER_SHEET_FORMAT is a set of AutoLISP routines for inserting a paper sheet based on a selected size and scale in AutoCAD. It supports predefined paper formats and scales, along with user-defined parameters. Quickpagesetup sets plot scope and scale without opening the Page Setup Manager. The routines can add a large title and scale information to the PaperSheet block, and can find a predefined size that encloses a drawn scope or selected objects.
Key capabilities
from the Autodesk App Store listingPaper sheet insertion
Inserts a PaperSheet block using a selected paper size and scale.
Custom sheet parameters
Allows user-defined paper sizes and scales in addition to predefined options.
Quick plot setup
Sets plot scope and scale through the Quickpagesetup command without entering the Page Setup Manager.
Sheet annotations
Adds an optional large title and scale information to the PaperSheet block.
Automatic size matching
Finds the nearest predefined size that encloses a drawn scope or selected objects.
In the catalog
311 plugins in AutoCAD · Documentation & Drafting
Price distribution: 80 free, 1 freemium, 230 paid
Pricing & deployment
Platform
Autodesk
Product
AutoCAD
Deployment
Desktop
Pricing
Paid
More from Andrzej Kalinowski
Similar plugins in AutoCAD · Documentation & Drafting
View all 311 →
Detail F/X
Manage, draft, call out, and update office CAD details within AutoCAD.
Land F/XPaid
Parametric Pipe Supports Plugin
Models parametric piping supports in AutoCAD Plant 3D with adjustable sizing and customization.
Mirza SolutionsPaid
Anaglyph (Inv)
Generates red-cyan 3D anaglyphs from Autodesk Inventor models.
ARKANCE CZ (CAD Studio)Free
What the vendor says
«This program is a set of AutoLISP routines that insert a Paper Sheet of the selected dialog window size and scale. The user can choose from standard paper sizes used around the world or their own user-defined size. The Quickpagesetup command allows you to set the plot scope and scale without entering the Page Setup …»
