Multi Dimensions
by Modeling StoreAutodeskPaid
Places aligned dimensions across multiple Revit grids, levels, and curtainwall grids.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
What it does
Multi Dimensions automatically adds several aligned dimensions for grids, levels, and curtainwall grids in Revit. Elements can be selected in plan, section, or elevation views, followed by a dimension type, the app's dimension control, and a point for placement. A designated control selects parallel grids or levels, including grids that are neither vertical nor horizontal.
Key capabilities
from the Autodesk App Store listingGrid dimensioning
Adds multiple aligned dimensions for grids in Revit.
Level dimensioning
Adds multiple aligned dimensions for levels in Revit.
Curtainwall grids
Adds multiple aligned dimensions for curtainwall grids.
Parallel selection
Selects parallel grids or levels, including grids that are non-vertical or non-horizontal.
View placement
Places dimensions in plan, section, or elevation views.
