MEP updown
by Modeling StoreAutodeskPaid
Modify Revit MEP elements by splitting them and applying upward or downward level offsets.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
MEP updown modifies ducts, pipes, cable trays, and conduits in Autodesk Revit by splitting elements and applying an offset and angle. It redraws the elements automatically and supports insulation and lining. Offset values use the project length unit, while angles range from 1 to 90 degrees. Fabrication elements are not supported, and the command is in English in all language versions.
Key capabilities
from the Autodesk App Store listingMEP element offsets
Applies upward or downward level offsets to ducts, pipes, cable trays, and conduits.
Element splitting
Splits MEP elements before applying the specified offset and angle.
Automatic redrawing
Redraws the modified elements after the offset and angle values are entered.
Insulation and lining
Supports MEP elements with insulation and lining.
Angle input
Accepts angle values from 1 to 90 degrees.
How it compares
MEP updown applies upward or downward offsets to ducts, pipes, cable trays, and conduits, with angle input from 1 to 90 degrees. Greater BIM bends the same MEP element types upward, downward, left, or right, but lists standard angles of 30, 45, 60, or 90 degrees. ToolBox includes MEP tools for connecting elements and splitting ducts and pipes, along with separate piping, ducting, and electrical tools.
| Name | Pricing | Deployment | Updated |
|---|---|---|---|
| this plugin | Paid | Desktop | |
| Greater BIM | Paid | Desktop | |
| ToolBox | Paid | Cloud |
In the catalog
555 plugins in Revit · Productivity & Utilities
Price distribution: 176 free, 1 freemium, 378 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Paid
More from Modeling Store
Similar plugins in Revit · Productivity & Utilities
View all 555 →
AutoInsulate
Automates insulation assignments for pipe, duct, and duct-lining systems in Revit.
TiMBIM bvPaid
MEP Package
Provides 31 tools for MEP system modeling, coordination, electrical work, and data exchange in Revit.
BIM SOFT SOLUTIONSPaid
ToolBox
Provides Revit tools for MEP modeling, coordination, parameter management, and schedule data extraction.
OssamaFree
What the vendor says
«This app helps MEP elements (duct, pipe, cable tray, and conduit) to modify level offset up or down. By splitting the elements and input offset/angle value, the app redraws elements automatically. It works with any language version of Autodesk® Revit®, but the command in English. It is useful for Revit HVAC, piping …»
