Lot Grading Tools
by Red Transit Consultants, LLCAutodeskPaid
Grades lots and pads, adds feature lines to surfaces, and labels grading plans in Civil 3D.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Provides tools for assigning elevations and grading settings to lot lines and pads selected with a fence. During grading, it can place feature lines on the active surface, including pad-offset reveal lines. A separate labeling tool marks lot line elevations, high points, pad elevations, and reveal elevations on grading plans.
Key capabilities
from the Autodesk App Store listingLot and pad grading
Applies grading settings and elevations to fence-selected lot lines and pads.
Surface feature lines
Places grading feature lines on the surface being edited.
Pad reveal lines
Creates a line at a specified offset from a pad for reveal-related grading.
Elevation checks
Includes checks used when setting lot and pad elevations.
Plan labeling
Labels lot line elevations, high points, pad elevations, and pad reveal elevations.
Use cases
- Set grades beside a pad using reveal settings.
- Specify a slope away from a pad for a rear patio.
- Add elevation labels to a lot grading plan.
In the catalog
513 plugins in Civil 3D · Design & Engineering
Price distribution: 158 free, 4 freemium, 351 paid
Pricing & deployment
Platform
Autodesk
Product
Civil 3D
Deployment
Desktop
Pricing
Paid
