Import/Export Surface Analysis
by Red Transit Consultants, LLCAutodeskPaid
Transfers surface analysis data between text files and surfaces in AutoCAD.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYData Exchange
UPDATED ON MARKETPLACE
What it does
Exports selected surface analysis data and related properties to a text file. Imports a previously exported file and applies its analysis information to another surface. Separate commands cover contour, directional, elevation, slope, slope-arrow, and user-contour analysis. The app also includes a style check for viewing analysis and supports ACI Colors, True Colors, and Color Books.
Key capabilities
from the Autodesk App Store listingAnalysis Data Export
Exports selected surface analysis information and related properties to text files.
Analysis Data Import
Applies analysis information from a previously exported text file to a selected surface.
Analysis Type Commands
Provides separate import and export commands for six surface analysis types.
Style Verification
Checks whether the surface style has been created correctly for displaying the analysis.
Color Type Support
Supports ACI Colors, True Colors, and Color Books during import and export.
In the catalog
97 plugins in AutoCAD · Data Exchange
Price distribution: 31 free, 66 paid
Pricing & deployment
Platform
Autodesk
Product
AutoCAD
Deployment
Desktop
Pricing
Paid
More from Red Transit Consultants, LLC
Similar plugins in AutoCAD · Data Exchange
View all 97 →
Detail F/X
Manage, draft, call out, and update office CAD details within AutoCAD.
Land F/XPaid
Parametric Pipe Supports Plugin
Models parametric piping supports in AutoCAD Plant 3D with adjustable sizing and customization.
Mirza SolutionsPaid
Anaglyph (Inv)
Generates red-cyan 3D anaglyphs from Autodesk Inventor models.
ARKANCE CZ (CAD Studio)Free
What the vendor says
«The app exports surface analysis and corresponding properties to text by selecting the export analysis type and a surface with that type of analysis applied to it. Then, as needed it will import a selected text file (previously exported) and apply it to a new surface with the exported analysis information. It also has …»
