JTB TrimWindow Trial
by JTB World Inc.AutodeskPaid
Copies selected drawing objects from a rectangular area and trims supported objects outside its edges.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
What it does
The app defines a rectangular selection by picking two corners, then trims and copies supported drawing objects within that area. The result can be placed elsewhere in the current drawing or copied to the clipboard. Supported types include 2D lines, curves, 3D polylines, dimensions, and leaders; text and hatches are copied without trimming. Copied 3D polylines are flattened to the XOY plane, while the originals remain unchanged.
Key capabilities
from the Autodesk App Store listingRectangular selection
Defines a selection area by picking two corners of a rectangle.
Object trimming
Trims supported drawing objects at the edges of the selected rectangle.
Drawing copy
Copies the resulting objects to another location in the current drawing.
Clipboard copy
Copies the resulting objects to the clipboard.
Supported object types
Handles 2D lines, curves, 3D polylines, dimensions, leaders, text, and hatches with different trimming behavior.
3D polyline flattening
Flattens copied 3D polylines to the XOY plane without changing the original objects.
Use cases
- Extracts details from a master plan drawing.
- Transfers a selected rectangular drawing area to another location or the clipboard.
