JTB FixRefs Trial
by JTB World Inc.AutodeskPaid
Batch-changes paths and names for external references in drawings.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
What it does
JTB FixRefs gathers references from selected drawings or folders into a spreadsheet. It shows existing paths and replacement paths for external files, and can locate missing files in many cases. After changes are specified, the app applies them across the selected drawings. It also supports path conversion, reference renaming, and detach, unload, reload, and bind operations.
Key capabilities
from the Autodesk App Store listingReference spreadsheet
Collects external references from selected drawings and displays their existing and replacement paths in a spreadsheet.
Batch path updates
Applies specified path changes to references across multiple drawings.
Missing file search
Can find missing referenced files in many cases and place their locations in the replacement-path field.
Path conversion
Converts paths between absolute and relative formats.
Reference operations
Can rename, detach, unload, reload, and bind reference objects.
Reference type support
Handles external references including Xrefs, Datalinks, raster images, PDFs, DWFs, and DGNs.
Use cases
- Process drawings stored in a folder and its subfolders.
- Filter the drawings and references before applying changes.
In the catalog
311 plugins in Documentation & Drafting
Price distribution: 80 free, 1 freemium, 230 paid
Pricing & deployment
Platform
Autodesk
Deployment
Desktop
Pricing
Paid
