Intersect Mesh Body
by AutodeskAutodeskFree
Generates sketch geometry from mesh intersections in Fusion 360.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Creates standard sketch geometry from where selected mesh bodies cross the x-y plane of the active sketch. The resulting geometry can be used for measurements and additional modeling.
Key capabilities
from the Autodesk App Store listingMesh section sketches
Produces standard sketch geometry from selected mesh bodies where they cross the active sketch's x-y plane.
Use cases
- Measure sections through imported mesh geometry.
- Use generated sketch sections as inputs for further modeling.
In the catalog
513 plugins in Fusion 360 · Design & Engineering
Price distribution: 158 free, 4 freemium, 351 paid
Pricing & deployment
Platform
Autodesk
Product
Fusion 360
Deployment
Desktop
Pricing
Free
More from Autodesk
Similar plugins in Fusion 360 · Design & Engineering
View all 513 →
ProtoTech's FBX Exporter for Autodesk® Fusion®
Exports Fusion 360 design models to FBX files with color, polygon reduction, orientation, and export-setting options.
ProtoTech Solutions and Services Pvt. LtdPaid
ProtoTech's GLTF Exporter for Fusion® - Trial
Exports Fusion 360 solid bodies and sketches to GLTF or GLB files.
ProtoTech Solutions and Services Pvt. LtdPaid
ProtoTech's FBX Exporter for Fusion® - Trial
Exports Fusion 360 design models to FBX files with adjustable export settings, polygon reduction, color preservation, and orientation control.
ProtoTech Solutions and Services Pvt. LtdPaid
What the vendor says
«This app allows you to more effectively and precisely use geometry imported from a mesh. Using this app you can cut sections through a mesh to create standard sketch geometry. You can then use the sketch geometry to perform precise measurements and to do additional modeling.»
