DXF Spline To Polyline
by AutodeskAutodeskFree
Export Fusion 360 sketches as DXF files with splines converted to polylines.
PRICINGFree
DEPLOYMENTNot published
CATEGORYData Exchange
UPDATED ON MARKETPLACE
What it does
Exports a selected or currently active Fusion 360 sketch to a DXF file. During export, the add-in converts splines into polylines.
Key capabilities
from the Autodesk App Store listingSketch DXF export
Exports a selected or currently active Fusion 360 sketch to a DXF file.
Spline conversion
Converts sketch splines into polylines in the exported DXF file.
Use cases
- Prepares sketch geometry for laser cutters that do not work with splines.
In the catalog
46 plugins in Fusion 360 · Data Exchange
Price distribution: 11 free, 35 paid
Pricing & deployment
Platform
Autodesk
Product
Fusion 360
Pricing
Free
More from Autodesk
Similar plugins in Fusion 360 · Data Exchange
View all 46 →
ProtoTech's FBX Exporter for Autodesk® Fusion®
Exports Fusion 360 design models to FBX files with color, polygon reduction, orientation, and export-setting options.
ProtoTech Solutions and Services Pvt. LtdPaid
ProtoTech's GLTF Exporter for Fusion® - Trial
Exports Fusion 360 solid bodies and sketches to GLTF or GLB files.
ProtoTech Solutions and Services Pvt. LtdPaid
ProtoTech's FBX Exporter for Fusion® - Trial
Exports Fusion 360 design models to FBX files with adjustable export settings, polygon reduction, color preservation, and orientation control.
ProtoTech Solutions and Services Pvt. LtdPaid
What the vendor says
«Autodesk® Fusion® add-in lets the user export the currently active sketch to a DXF file in which the splines have been converted to polylines. Some laser cutters do not work with splines. In order to avoid having to open the DXF in another product to do the conversion, this add-in does that for you.»
