HVACBlocks
by Tharwat Al ShoufiAutodeskPaid
Import and insert HVAC blocks into current AutoCAD drawings using a selected scale.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
What it does
HVACBlocks imports HVAC blocks and inserts them into the current drawing according to a selected scale. The vendor states that the trial version works approximately 250 times and can be activated to obtain the full version before expiry.
Key capabilities
from the Autodesk App Store listingHVAC block import
Imports HVAC blocks for use in the current drawing.
Drawing insertion
Inserts imported HVAC blocks into the current drawing.
Scale-based placement
Uses the selected scale when importing and inserting HVAC blocks.
Who it's for
HVAC engineers and draftsmen.
In the catalog
311 plugins in AutoCAD · Documentation & Drafting
Price distribution: 80 free, 1 freemium, 230 paid
Pricing & deployment
Platform
Autodesk
Product
AutoCAD
Deployment
Desktop
Pricing
Paid
