Fire Fighting
by Tharwat Al ShoufiAutodeskPaid
Drafts fire-fighting system pipes and fittings in AutoCAD using selectable sizes and drawing scales.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Drafts pipes and related fittings for fire-fighting systems in AutoCAD. It provides pipe sizes from 20 to 200 mm, separate dialogs for each size, and a dialog for inserting fitting symbols as blocks. The drawing scale must be set to 1.0 or 1000.0 before starting, and the trial can be used 350 times.
Key capabilities
from the Autodesk App Store listingPipe size range
Provides pipe sizes from 20 to 200 mm.
Size-specific dialogs
Includes a separate dialog box for each pipe size.
Fitting symbol blocks
Provides a dialog box for inserting fitting symbols as blocks.
Drawing scale options
Works with drawing scales of 1.0 and 1000.0 units.
In the catalog
513 plugins in AutoCAD · Design & Engineering
Price distribution: 158 free, 4 freemium, 351 paid
