FILTER SELECTION
by Andrzej KalinowskiAutodeskPaid
Filter AutoCAD objects by properties such as type, layer, color, block, linetype, text, length, and area.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
Provides AutoLISP routines for filtering objects in AutoCAD by object type, layer, color, block name, linetype, lineweight, linetype scale, or TEXT and MTEXT content. It can also filter objects by length or area when those properties are available, including MEP objects. Filtering can use the current selection or the entire drawing, and multiple object types can be selected in one step. Search phrases can narrow long property lists and add matching items to the existing selection.
Key capabilities
from the Autodesk App Store listingProperty-based filtering
Filters objects by type, layer, color, block name, linetype, lineweight, and linetype scale.
Text content filtering
Filters TEXT and MTEXT objects by their text content.
Length and area filtering
Filters objects by length or area when the selected objects have the relevant property, including MEP objects.
Multiple type selection
Allows multiple object types to be selected in one filtering step.
Selection scope
Applies filtering to the current selection or to the entire drawing.
List phrase search
Narrows long lists by entering phrases contained in the listed items.
In the catalog
1,097 plugins in AutoCAD · Productivity & Utilities
Price distribution: 389 free, 19 freemium, 689 paid
Pricing & deployment
Platform
Autodesk
Product
AutoCAD
Deployment
Desktop
Pricing
Paid
