Create Dimensions in 3D Views
by Content OriginAutodeskFree
Adds 3D work planes and dimensions from selected MEP elements or existing dimensions.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
What it does
Creates work planes and dimensions in 3D views from selected MEP elements or existing dimensions. A preview appears when an element or dimension is selected, and selecting the same point again rotates the work plane around the element. The vendor describes its use for assembly and spool drawings.
Key capabilities
from the Autodesk App Store listing3D work planes
Creates work planes in 3D views from selected MEP elements or existing dimensions.
3D dimensions
Generates dimensions in 3D views from selected MEP elements or existing dimensions.
Work plane preview
Shows a preview of the work plane after an MEP element or existing dimension is selected.
Work plane rotation
Rotates the work plane around an MEP element when the same point is selected again.
