Complete Corner
by Marek SepsAutodeskFree
Dimensions beveled edges using lines or polylines in a CAD drawing.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
What it does
Complete Corner supports dimensioning beveled edges that lack an obvious starting point. It works with lines and polylines and can use either a specified layer or the current layer.
Key capabilities
from the Autodesk App Store listingBeveled edge dimensioning
Supports dimensioning for beveled edges without an obvious beginning.
Line support
Works with lines and polylines.
Layer selection
Allows a specified layer, such as a non-plot help layer, or the current layer.
In the catalog
311 plugins in Documentation & Drafting
Price distribution: 80 free, 1 freemium, 230 paid
Pricing & deployment
Platform
Autodesk
Deployment
Desktop
Pricing
Free
Similar plugins in Autodesk · Documentation & Drafting
View all 311 →
KeyNote Magic
Assigns and manages project keynotes, including reporting and 3D visualization.
PROISAC-BIM-VDCPaid
Content Pack For GF Piping Systems - KLIP-IT
Adds pipe clips and spacers to Autodesk AutoCAD Plant 3D.
GF Piping Systems Ltd.Free
FX64 Plot 2027
Prints and converts Inventor drawing files, including files associated with assemblies and files stored in Vault.
FX64 Software SolutionsPaid
What the vendor says
«The application complements the beveled corner. It's useful for the dimensioning of beveled edges, which have no obvious beginning. Features: • It works with lines and polylines. • You can specify your own layer (for example, a non-plot help layer), or you can use the current layer.»
