Sheet Metal DXF Exporter
Exports Inventor sheet metal assembly flat patterns to DXF with metadata and optional geometry processing.
MicrographicsPaid
AUTO-CUSTOM-FLAT
by LDESIGN / Lukas Loechert /AutodeskFree
Converts Autodesk Inventor sheet metal parts into flat-pattern DXF files and supports batch processing with export options.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYData Exchange
UPDATED ON MARKETPLACE
What it does
Converts sheet metal part files from Autodesk Inventor into flat-pattern DXF files. The add-in provides multiple export settings and can process many files in a single action.
Key capabilities
from the Autodesk App Store listingFlat-pattern DXF export
Creates flat-pattern DXF files from Autodesk Inventor sheet metal parts.
Export settings
Offers multiple options for the DXF export process.
Batch processing
Processes many files in a single user action.
How it compares
AUTO-CUSTOM-FLAT converts Autodesk Inventor sheet metal parts into flat-pattern DXF files and supports batch processing. Sheet Metal DXF Exporter exports flat-pattern parts from an assembly and can add part number, material, thickness, and quantity information to DXF files or their file names.
