Wood-Joints
by PICSandPIXELSAutodeskPaid
Generate wooden box joint drawings, bottom milling details, and dimensions in Fusion 360.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
What it does
Wood-Joints takes box measurements and produces drawings for either dove joints or box joints. It also shows the bottom milling and provides the resulting dimensions.
Key capabilities
from the Autodesk App Store listingBox measurement input
The app accepts measurements for a wooden box.
Dove joint drawings
It generates drawings of dove joints.
Box joint drawings
It generates drawings of box joints.
Bottom milling details
It shows the milling for the box bottom.
Dimension listing
It provides the box dimensions in a list.
Use cases
- Woodworkers can preview boxes and drawers before construction.
Who it's for
Woodworkers.
