Wall Chamfer (Trial)
by BIMODELAutodeskPaid
Creates chamfered walls between selected walls in an Autodesk Revit file.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Wall Chamfer creates a chamfered wall after two walls are selected in an Autodesk Revit file. Configuration options cover the wall type, placement reference, vertical constraints, height offsets, and unconnected height. The command can remain active for multiple chamfers and includes an option to trim the original walls.
Key capabilities
from the Autodesk App Store listingWall chamfer creation
Creates a chamfered wall between two selected walls in a Revit file.
Wall property settings
Sets the new wall's type, placement reference, vertical limits, height offsets, and unconnected height.
Optional wall trimming
Allows the main walls to be trimmed or left untrimmed.
Repeated wall creation
Keeps the command available for creating additional chamfered walls until it is canceled.
Use cases
- Chamfering wall corners in hospitals and clinics.
- Creating wall corners subject to stated design codes and standards.
In the catalog
72 plugins in Revit · Design & Engineering
Price distribution: 22 free, 2 freemium, 48 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Paid
