Voussoir
by BUILT CoLABAutodeskFree
Creates and edits parametric stereotomic vaults with voussoirs and springers inside Revit.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Generates stereotomic vaults in Revit after selection of two opposite walls. Vault geometry can be modified by changing the profile, height, thickness, and subdivision pattern. Included voussoir and springer families are placed in model groups, and the resulting geometry can be exported in formats such as OBJ and STL.
Key capabilities
from the Autodesk App Store listingVault generation
Creates a stereotomic vault from two opposite walls with initial default settings.
Parametric editing
Provides controls for the vault profile, height, thickness, and subdivision pattern.
Included Revit families
Uses dedicated voussoir and springer families supplied with the plugin.
Geometry export
Exports the generated vault geometry to OBJ, STL, and other external formats.
In the catalog
72 plugins in Revit · Design & Engineering
Price distribution: 22 free, 2 freemium, 48 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Free
Similar plugins in Revit · Design & Engineering
View all 72 →
TA Solids Extractor
Creates 3D solids from selected Civil 3D surfaces and corridors, with options for DWG output.
TA SolutionsPaid
Schedule Toolbox
Create, export, analyze, and consolidate measurement tables within Autodesk Revit.
PROISAC-BIM-VDCPaid
Real Time Clash
Detects interferences in Revit while modeling MEP and other categories, including linked files.
PROISAC-BIM-VDCPaid
What the vendor says
«The Voussoir for Autodesk® Revit® plugin is designed to create stereotomic vaults directly within the BIM environment. Combining advanced geometric logic with principles inspired by traditional masonry construction, the plugin enables users to generate, edit, and export vault systems composed of voussoirs and …»
