Topo Align
by russ greenAutodeskFree
Aligns Revit topography surfaces and solids with model elements, edges, lines, contours, and intersections.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Topo Align provides commands for editing Revit topo surfaces and topo solids in Revit 2024 and later. It can align topography with walls, floors, roofs, pads, edges, selected faces, model lines, arcs, and contour lines, using offsets where specified. The add-in can create topo points from projected lines, contour lines, and surface intersections. It can also reset part of an edited topo surface by replacing internal points with points from an existing surface.
Key capabilities
from the Autodesk App Store listingAlign to elements
Aligns topo surfaces or solids with the top or bottom face of selected walls, floors, roofs, or pads, with variable vertical offsets.
Align to edges
Aligns topo surfaces or solids to individual element edges, with limited support for families.
Align to topo
Adds points from a selected topo surface to a floor; in Revit 2024 and later, converts the floor to a region on the topo solid.
Project model lines
Projects model lines and arcs below a topo surface onto it as additional topo points.
Create contour points
Creates topo points along model lines used as contour lines at specified distances, with an offset value available for controlling point elevation.
Add intersection points
Creates topo points where a selected face, such as a wall, floor, roof, or mass, intersects a topo surface.
Reset surface regions
Removes internal points from an edited topo surface within a picked area and copies points from an existing topo surface into that area.
In the catalog
513 plugins in Revit · Design & Engineering
Price distribution: 158 free, 4 freemium, 351 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Free
