TL Grade Tool
by Todor LatevAutodeskFree
Generates dynamic grade lines at user-specified grades for road profile, grading, and civil engineering design workflows.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
TL Grade Tool generates dynamic lines at user-specified grades. It supports forward and backward grades, vertical scale factors, and WCS and UCS. Parameters can be customized and displayed live on screen, with shortcuts for common grades from 0% to 9%.
Key capabilities
from the Autodesk App Store listingDynamic grade lines
Generates lines dynamically at user-specified grades.
Vertical scale factors
Supports vertical scale factor settings.
WCS and UCS support
Supports WCS and UCS.
Grade directions
Supports forward and backward grades.
Custom parameters
Provides customizable parameters.
Live parameter display
Displays parameters on screen.
Grade shortcuts
Provides dedicated shortcuts for grades from 0% to 9%.
Use cases
- Road profile design can use dynamic lines at specified grades.
- Grading and other civil engineering design workflows can use the grade line generation tool.
In the catalog
513 plugins in AutoCAD · Design & Engineering
Price distribution: 158 free, 4 freemium, 351 paid
Pricing & deployment
Platform
Autodesk
Product
AutoCAD
Deployment
Desktop
Pricing
Free
