SwitchBackClash
by D'Bim ToolsAutodeskPaid
View Navisworks clash reports in Revit and place families at clash points.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYBIM Collaboration
UPDATED ON MARKETPLACE
What it does
Imports an XML clash report exported from Navisworks into Revit. The workflow starts by selecting SwitchBackClash, browsing to the XML report, and choosing a family for placement at clash points. The default family can be loaded, or a custom family can be used. Selected family parameters can receive clash information.
Key capabilities
from the Autodesk App Store listingXML Clash Import
Opens clash reports exported from Navisworks in Revit.
Clash Point Placement
Places a selected family in the Revit model at clash points.
Custom Family Support
Allows the default family or a user-provided family to be used.
Parameter Mapping
Writes clash information to selected family parameters.
Who it's for
Revit users reviewing clashes created by Navisworks.
How it compares
SwitchBackClash imports a Navisworks XML clash report and places a selected family at clash points, while Clash Navigator and Clash Manager focus on viewing, navigating, selecting, and isolating reported clashes within the Revit interface. Clash Navigator and Clash Manager are listed as free, while SwitchBackClash is listed as paid.
| Name | Pricing | Deployment | Updated |
|---|---|---|---|
| this plugin | Paid | Desktop | |
| Clash Navigator | Free | Desktop | |
| Clash Manager | Free | Desktop |
In the catalog
56 plugins in Revit · BIM Collaboration
Price distribution: 24 free, 32 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Paid
