Slope Pattern with Benches
by ADSON A N BALBINO ENGENHARIAAutodeskPaid
Draws slope patterns between polylines in Civil 3D, with configurable tick intervals, orientation, and bench dimensions.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Draws a slope pattern between two polylines in Civil 3D. A dialog box sets tick spacing, pattern orientation relative to the top or bottom polyline, and benching parameters. When benching is selected, the command uses the specified bench distance and width.
Key capabilities
from the Autodesk App Store listingPolyline slope patterns
Draws a slope pattern between two polylines.
Pattern orientation
Sets the pattern perpendicular to either the bottom or top polyline.
Tick interval control
Sets the distance between pattern ticks.
Bench parameters
Defines bench distance and bench width for patterns that include benching.
