SKEN COLUMN
by NOUWD.AutodeskPaid
Checks Revit structural columns against CAD links and flags positional or dimensional differences.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYData Exchange
UPDATED ON MARKETPLACE
What it does
SKEN COLUMN examines the area around each Revit structural column to find matching CAD geometry. It identifies positional drift, size differences, and minor drafting noise using the vendor's stated tolerances. The add-in can place revision clouds and warning tags in the current Revit view. Its audit log shows Revit IDs, drift measurements, and dimensional comparisons.
Key capabilities
from the Autodesk App Store listingCAD reconciliation
Compares Revit structural columns with corresponding geometry from CAD links.
Proximity scanning
Searches near each Revit column insertion point for matching CAD geometry.
Drift detection
Identifies positional drift at the stated 10mm tolerance.
Size comparison
Detects dimensional differences at the stated 30mm and 50mm thresholds.
Visual discrepancy markers
Adds revision clouds and warning tags to the current Revit view.
Audit logging
Lists Revit IDs, measured drift values, and dimensional comparisons.
In the catalog
143 plugins in Revit · Data Exchange
Price distribution: 64 free, 2 freemium, 77 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Paid
