Self-Aligning Jig
by Maciej RogowskiAutodeskPaid
Builds sketch geometry for a jig that aligns two-sided machined parts.
PRICINGPaid
DEPLOYMENTNot published
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
The add-in generates sketch geometry for a self-aligning jig used with two-sided parts. Inputs include two opposite rectangle corners and the tool diameter. The vendor identifies woodworking as a particular use.
Key capabilities
from the Autodesk App Store listingJig Geometry Creation
Generates sketch geometry for a self-aligning jig.
Corner Specification
Accepts the bottom-left and top-right corners of a rectangle.
Tool Diameter Input
Accepts a tool diameter for the jig geometry.
Use cases
- Woodworking projects involving parts machined on two sides.
In the catalog
513 plugins in Design & Engineering
Price distribution: 158 free, 4 freemium, 351 paid
