Renumber vertices polyline
by AK-ProjectAutodeskFree
Reorders the vertices of a selected polyline while preserving its other properties.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
This application changes the order of vertices in a selected polyline. The workflow specifies which point should become the first vertex and which should become the second. The polyline’s coordinates, layer, color, thickness, and other properties remain unchanged. For a closed polyline, any selected vertex can become the first vertex.
Key capabilities
from the Autodesk App Store listingSelect polyline
The workflow starts by selecting a polyline.
Set vertex order
Points on the selected polyline can be specified as the first and second vertices.
Preserve properties
Changing the vertex order does not change the polyline’s coordinates, layer, color, thickness, or other properties.
In the catalog
1,097 plugins in Productivity & Utilities
Price distribution: 389 free, 19 freemium, 689 paid
Pricing & deployment
Platform
Autodesk
Deployment
Desktop
Pricing
Free
