衝突チェック用ボルト ― Python スクリプト
by PTS CO., LTDAutodeskPaid
Creates bolt geometry for interference checks in AutoCAD Plant 3D piping designs.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
This Python script catalog provides bolts for checking interference during piping design in AutoCAD Plant 3D. The bolts are intended for design-stage use when evaluating potential clashes with piping components, supports, and surrounding structures. It represents bolt dimensions and supports use at flange connections, pipe supports, and related structural interfaces. The catalog supports Plant 3D versions 2025 and 2026 and uses a custom installer rather than the standard App Store installer.
Key capabilities
from the Autodesk App Store listingInterference-check bolts
Provides bolts for identifying and evaluating clashes with piping during layout and routing.
Bolt geometry creation
Creates bolt shapes with reproduced bolt dimensions for piping interference checks.
Flange interface support
Supports use at flange connections, pipe supports, and structural interfaces common in piping systems.
Plant 3D compatibility
Supports Autodesk AutoCAD Plant 3D versions 2025 and 2026.
