OsnapPalette
by Gilles ChanteauAutodeskPaid
Sets running object snap modes and prompt-specific point modifiers with a dockable palette.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
OsnapPalette provides a dockable palette for setting running Object Snap modes and selecting an object snap, point filter, or MTP option at a point prompt. Custom snaps divide curve lengths into specified fractions, including thirds and quarters, and locate centroids on arcs, polylines, regions, and 3D solids. Custom modes can also be used with the OSNAP command, at point prompts, or through AutoLISP. System variables control custom running snaps and the fraction denominator.
Key capabilities
from the Autodesk App Store listingRunning snap modes
The palette sets running Object Snap modes.
Prompt point modifiers
The palette provides object snaps, point filters, and MTP options at a point prompt.
Fraction curve snaps
Custom snaps locate specified fractions of arcs, circles, ellipses, lines, and polyline segments.
Centroid snapping
A custom snap locates centroids on arcs, polylines, regions, and 3D solids.
AutoLISP support
Custom snap modes and their system variable values can be used with AutoLISP functions.
In the catalog
1,097 plugins in Productivity & Utilities
Price distribution: 389 free, 19 freemium, 689 paid
Pricing & deployment
Platform
Autodesk
Deployment
Desktop
Pricing
Paid
