OBJ2DWG
by ARKANCE CZ (CAD Studio)AutodeskFree
Imports simple OBJ mesh files into AutoCAD as PolyFace mesh objects.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYData Exchange
UPDATED ON MARKETPLACE
What it does
Imports simple OBJ files into Autodesk AutoCAD and represents the imported meshes as PolyFace mesh objects. Files can contain up to 32767 vertices due to the PolyFace object limitation.
Key capabilities
from the Autodesk App Store listingOBJ file import
Imports simple OBJ mesh files into AutoCAD.
PolyFace mesh output
Represents imported OBJ meshes as PolyFace mesh objects.
Vertex limit
Supports OBJ files with up to 32767 vertices because of the PolyFace object limitation.
