Northing and Easting Parameters
by Sanjiv KapilaAutodeskPaid
Adds coordinate fields that Revit can schedule for PHE equipment and other Site-category components.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
This Revit add-in adds Northing and Easting shared parameters to PHE equipment and other families in the Site category. The resulting values can be included in schedules and tags. A shared-parameter file is provided in the application’s Resources folder as an aid for setting up the parameters.
Key capabilities
from the Autodesk App Store listingCoordinate fields
Adds Northing and Easting shared parameters to families in Revit’s Site category.
Schedule support
Makes the added coordinate values available for Revit schedules.
Tag support
Allows the shared coordinate parameters to be used in Revit tags.
Parameter resource
Provides a shared-parameter file in the application’s Resources folder.
Use cases
- On large sites, the add-in can be used with PHE equipment such as manholes and inspection chambers.
How it compares
Northing and Easting Parameters adds Northing and Easting fields to PHE equipment and other Site-category components. Pile Coordinates works with Structural Column/Pile and Structural Foundation categories and provides X, Y, Z, Easting and Northing coordinates.
| Name | Pricing | Deployment | Updated |
|---|---|---|---|
| this plugin | Paid | Desktop | |
| Pile Coordinates | Paid | Desktop |
In the catalog
555 plugins in Revit · Productivity & Utilities
Price distribution: 176 free, 1 freemium, 378 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Paid
More from Sanjiv Kapila
Similar plugins in Revit · Productivity & Utilities
View all 555 →
TA Solids Extractor
Creates 3D solids from selected Civil 3D surfaces and corridors, with options for DWG output.
TA SolutionsPaid
Schedule Toolbox
Create, export, analyze, and consolidate measurement tables within Autodesk Revit.
PROISAC-BIM-VDCPaid
Real Time Clash
Detects interferences in Revit while modeling MEP and other categories, including linked files.
PROISAC-BIM-VDCPaid
What the vendor says
«Northing and Easting parameters for PHE equipment is an Autodesk® Revit® Add-in. The default behavior of Revit does not allow us to schedule the spot coordinates or the Northing and Easting values of components. However, this functionality is particularly desirable for PHE (Public Health Engineering) equipment …»
