MatchRotation
by Juan Osborne - WiseBuild.esAutodeskPaid
Match Z rotation between Revit elements, including views, boxes, annotations, detail items, and linked-model elements.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
MatchRotation matches the Z rotation of almost any Revit element. It can rotate section and elevation views, scope boxes, section boxes, annotations, detail items, and plan views by using another element as the alignment target. The tool provides Pair Wise, Reverse Pair Wise, and One to Multiple modes, and can work with elements in linked models.
Key capabilities
from the Autodesk App Store listingZ Rotation Matching
Matches the Z rotation between almost any Revit element.
View Rotation
Rotates section views, elevation views, and plan views against selected alignment targets.
Box Alignment
Rotates scope boxes and section boxes to align with walls or grids.
Annotation Rotation
Rotates annotations and detail items.
Perpendicular Rotation
Shift-clicking a target rotates the element perpendicular to that target.
Multiple Rotation Modes
Supports Pair Wise, Reverse Pair Wise, and One to Multiple modes.
Linked Model Elements
Works with elements in linked Revit models.
In the catalog
555 plugins in Revit · Productivity & Utilities
Price distribution: 176 free, 1 freemium, 378 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Paid
