ExtrudeLines [2025]
by Stéphane KAPETANOVICAutodeskFree
Generate walls in Autodesk Robot Structural Analysis from lines, polylines, contours, bars, and floor elements.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
![ExtrudeLines [2025] — cover image](https://ylpowcxbmmpfxqdk.public.blob.vercel-storage.com/autodesk/extrudelines-2025.webp)
What it does
ExtrudeLines creates walls from bars, superbars, lines, polylines, contours, arcs, fillets, slabs, openings, and floor beams. A wall can be defined by a height or an arrival plane, with extrusion along a selected axis or projection plane. The workflow supports global or local systems, optional deletion of source elements, added cutting planes, and an always-on-top dialog with process refresh.
Key capabilities
from the Autodesk App Store listingWall generation
Creates walls from bars, superbars, lines, polylines, contours, arcs, fillets, slabs, openings, and floor beams.
Extrusion controls
Sets an extrusion distance, direction, projection plane, or arrival plane for the generated walls.
Coordinate systems
Allows extrusion settings to use either a global or local system.
Cutting planes
Adds object planes for cutting extrusions where the planes do not align with the main axes.
Process monitoring
Provides an always-on-top dialog with a refresh mode for tracking extrusion progress.
Use cases
- Model walls on multiple floors from floor slabs, openings, or beams.
- Create wall geometry from lines or polylines in a DXF or DWG background.
In the catalog
