DimensionSet
by Richard StimaAutodeskFree
Group and edit continuous dimension sets as one object in AutoCAD.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYDocumentation & Drafting
UPDATED ON MARKETPLACE
What it does
DimensionSet groups qualifying dimensions into one continuous dimension set and provides commands to insert or delete points, move the baseline, and modify extension lines. It also modifies extension-line and point-symbol properties and allows selection of a dimension set. The app supports rotated dimensions created with DIMLINEAR.
Key capabilities
from the Autodesk App Store listingInsert dimension points
Adds a new point to a dimension set.
Delete dimension points
Removes a point from a dimension set.
Move dimension baseline
Moves the baseline of a dimension set.
Modify extension lines
Changes the length of extension lines in a dimension set.
Edit line properties
Modifies extension-line and point-symbol properties.
Select dimension sets
Selects a dimension set as one object.
In the catalog
311 plugins in AutoCAD · Documentation & Drafting
Price distribution: 80 free, 1 freemium, 230 paid
Pricing & deployment
Platform
Autodesk
Product
AutoCAD
Deployment
Desktop
Pricing
Free
