Diffusers To Ceilings
by Sigma AEC SolutionsAutodeskPaid
Moves Revit diffusers to the ceilings they correspond to.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
Identifies the ceiling associated with a diffuser and relocates the diffuser to it. The tool works with ceilings in the current model and linked models, including their height and level. The vendor describes use after a linked model reload changes a ceiling position or a diffuser loses its ceiling or work-plane association.
Key capabilities
from the Autodesk App Store listingCeiling association
Identifies the ceiling that corresponds to a diffuser.
Diffuser relocation
Moves a diffuser to its corresponding ceiling.
Linked model support
Works with ceilings from linked models as well as the current model.
Level detection
Determines the relevant ceiling height and level.
Use cases
- Reposition diffusers after a linked model reload changes a ceiling's elevation.
- Restore diffuser placement after its ceiling or work-plane association is lost.
In the catalog
555 plugins in Revit · Productivity & Utilities
Price distribution: 176 free, 1 freemium, 378 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Paid
More from Sigma AEC Solutions
Similar plugins in Revit · Productivity & Utilities
View all 555 →
ETools – Placement
Places Revit family instances between points or in evenly spaced arrays.
Burlakov EvgeniiFree
Bird Tools - CAD Link Opener
Open linked DWG files from Revit in a new or running AutoCAD instance or default DWG handler.
Building Information Researchers and Developers OÜFree
Bird Tools - Match Offset
Match selected Revit elements to the first element’s height or offset in any view type.
Building Information Researchers and Developers OÜFree
What the vendor says
«The Diffusers to Ceilings tool detects the ceiling to which the diffuser should be moved to and moves the diffuser to its corresponding ceiling. It supports model and linked ceilings and is able to detect the correct ceiling height and level. It proves to be crucial in several instances, especially whenever an …»
